HAK Pneumatic (4 WAY / 5 PORT / 2 POSITION) Mechanical Valve with Detent Toggle Switch NPT 1/4”. (MPV 522)
Regular price
$51.64
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Description
* Pneumatic Mechanical Valve with Detent Toggle SwitchValve Type: 5 Port 2 Position.* A High-Quality Valve body is made of Aluminium material, with long-serving life; seals initially imported from Japan.* The Anti-friction seal is added at both ends of the valve spool to make the valve spool more stable during the switching process and increase the valve lifetime.* This is a four-way, air-pilot valve with a spool design requiring an input pressure supplied to port P to actuate. The valve will not actuate when no pressure is applied.* This type of valve is designed for AIR FLOW ONLY. The use of filtered lubricated air will prolong the life of the valve & its internal components.Specification
| Model | MPV522 |
|---|---|
| Working Medium | 40 Micron Filtered Air |
| Port Size | 1/4" |
| Effective Cross Section Area | 18 mm 2 (CV = 1.00) |
| Working-pressure | 21.75～116 PSI |
| Working Temperature | -20～70℃ |
