HAK Pneumatic CB Series Rear Clevis Bracket For ISO 15552 Series Air Cylinder

SKU: CB SERIES

Use this text to encourage communication or promote sharing on social networks.

You can also add links

Overall Dimensions

Edit
CB SERIES 32 40 50 63 80 100 125
S 45 52 65 76 97 112 140
T 32.5 38 46.5 56.5 72 89 110
D 6.5 6.5 8.5 8.5 10.5 10.5 12.5
E 14 17 17 22 24 25 30
RR 6.5 6.5 9 9.5 11 11.5 12
CB 34 41 54 65 83 101 123
CC 22 25 27 32 36 41 50
CD 10 11 13 16 46 20 25
CE 10 12 12 16 16 20 25
CP 26 28 32 40 50 60 70
CT 45 52 60 70 90 110 120
PA1 53 60 68 78 100 120 130
PB1 46.5 53.5 61.5 71.5 91.5 111.5 121.5
