HAK Pneumatic Direct Manifold for 4V200 Valve Series
Regular price
$2.50
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
Dimensions
| Inside Dia./ Symbol | A | B | C | E | F | G | K | KA | L | M | Q | R | S | W | X | Y |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4V200 | 59 | 50 | 21 | 4.3 | 22.2 | 23 | 170 | (n-1)*23+34 | (n-1)*23+46 | 189 | NPT 1/4' | 43 | 32 | 92.5 | 26 | 35 |
